SunSpot 36 Equinox Dual-Function LED Landing & Taxi Light | 14 V

Product Description

The SunSpot 36 Equinox is the highest-value PAR36 lighting solution offered by AeroLEDs, combining 100W Landing and Taxi performance with integrated Pulse functionality in a single LED platform. Designed for pilots operating in night, day, and reduced-visibility conditions, the Equinox delivers full dual-mode capability in one PAR36 footprint—ideal for single-light or multi-light installations.

In landing mode, the Equinox delivers a focused 20° × 20° beam optimized for takeoffs and landings. In taxi mode, it transitions to a wider 35° × 50° beam for broad, uniform illumination during ground operations. Integrated Pulse (WigWag) Technology comes standard, improving aircraft conspicuity while operating without external controllers and drawing up to 50% less current than incandescent systems.

Built on the proven SunSpot Series platform, the Equinox provides superior total light output and beam quality while drawing less power than traditional incandescent lamps. Its high-efficiency optical system produces a clean, daylight-white color temperature that reveals the true color and contrast of runway markings and terrain—eliminating the dull, amber cast of legacy bulbs. Built to withstand the rigors of flight, SunSpot 36 Equinox mounts directly into standard PAR36 housings, with straightforward wiring to enable dual-mode and Pulse operation.

This SunSpot 36 Equinox Dual-Function LED Landing & Taxi Light (EDMO# 36EQUINOX1) is a 14-volt unit.

Specifications

• Weight:
  11.06 oz
• Dimensions:
  4.4 x 4.4 x 2.1 in
• Mounting:
  Fits standard PAR 36 mounts
• Voltage:
  9–15 VDC, 14 VDC (Nominal)
• Current:
  Landing: 7.1 A Taxi: 5.4 A
• Power:
  100 W
• Peak Candela:
  200k (Peak)
• Beam Profile (@ 10% Peak) :
  Landing: 20° x 20° Taxi: 35° x 50°
• Lifespan:
  30,000 hours
• Lens Material:
  UV-coated polycarbonate
• Approvals:
  FAA-PMA/STC

Product Codes

• Mfr Part No
  01-1030-LT-12
• SCHEDULE B CODE
  8539.10.0030
