Carbon A1 Active ANR Headset | General Aviation Plugs

Product Description
The Carbon A1 extremely lightweight headset features active noise cancellation and contains premium features at an affordable value. The passive noise reduction attenuates background noise up to 23 dB and with active noise reduction enabled, and additional 18 dB – 22 dB of noise is quieted — making the Carbon A1 headset the quietest in its class. Closer tolerances during its design and construction along with mil-spec components, provides this headset more stability and performance. Soft air-foam head pad provides excellent comfort for pilots, thus eliminating ""hot spots"". Protein leather ear-seals are comfortable against the ears while providing comfort and noise attenuation.
Also, available in a panel mounted and helicopter version.
Features
- 30% lighter with carbon fiber construction
- Two simultaneous connections
- Record out functionality to send audio to camera, digital recorder, or smartphone
- External power soure via USB-C port
- AUX input and dual volume control
- 20—25 hours of operation on 2xAA batteries
- Detachable comm cord offers different applications (GA, Heli, 6-pin lemo)
- 19 dB — 21 dB at 150 Hz ANR
- 24 dB passive noise reduction
- Auto-shut off
- Mono & stereo capability
- Protein leather ear seals
- Air-foam head pad
- Adjustable ""memory"" flexible microphone boom
- Auxiliary audio interface for music, checklists, and warnings
- Custom padded protected case
- Noise cancelling electret microphone
- Foam windscreen
Specifications
Weight:
10 oz (284 g)
Passive NRR:
24 dB
Active NRR:
additional 18 dB — 22 dB at 150 Hz
Microphone Type:
noise canceling amplified electret mic
Speaker Impedance:
300Ω
Cord Type:
5-foot straight
Plug Type:
0.25in audio & 0.206in mic
Boom Type:
full flex
Product Codes
- Mfr Part No:CARBON A1
- EDMO #:CARBON A1
- Brand:PILOT COMMUNICATIONS USA
- Category:Headsets & Intercoms
- SCHEDULE B CODE:8518.30.2000
