EC2002 Altitude Encoder

MICROAIR

Call For Pricing

Available to order

EDMO # 20000031

MFR Part # 20000031

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The EC2002 accurately reports aircraft altitude over a calibrated altitude range of -1,000 to 35,000 feet. The low operating voltage makes this encoder ideal for battery only operations. It is a lightweight unit — weighing only 3.25 oz, and has pre-drilled holes allow for easy installation. The connection for the EC2002 altitude encoder consist of a DB15 connector and a 1/8-inch NPT fitting for measuring static air pressure. The contact pin assignments emulate that of most common encoders — making the EC2002 an ideal update to replace older encoders.

Features

Accurately reports the aircraft altitude over a calibrated altitude range of -1000 to 35,000ft
Output can return over 10-line Gillham “Gray” code or a 2-line serial data output
Extremely low power requirements: 10–125 mA consumption
Compact and lightweight: 3.25 oz (95g)
Pre-drilled, flanged chassis offers simple mounting

Specifications

Weight:

95 g Dimensions: 3.23 x 3.54 x 1.34 (82 x 90 x 34 mm) Connections: Electrical Pneumatic DB-15 Sub D miniature 1/8” NPT Internal Thread Altitude Range: -1,000 to 35,000 ft (Factory Calibrated) Temperature Operational: -20°C to 55°C Time to first altitude Code: Above 0˚: 10 seconds Input Voltage: 10V – 33V Power Consumption: Without heater element — 15mA 14V: With heater element — 125mA 28V: With heater element 200mA — 200mA Code Output: Serial (RS232): Microair ASCII, Garmin AT, Garmin Northstar, Garmin Trimble, Magellan Parallel: Gillham Code
