M27500-20TG4T14 Extruded ETFE Tefzel™ Wire | 20 AWG, 4-Conductor
EDMO DISTRIBUTORS, INC
EDMO#: 20TG4T14
MFR#: M27500-20TG4T14
Description
SAE AS22759/18 is made of special extruded ETFE insulation covering a tin-plated copper conductor. It is light-weight and provides the mechanical toughness and durability suitable for extreme aerospace, military, and commercial environments. This AS22759 wire has a fluoropolymer–insulation and single-conductor offering high performance and reliability in severe wind and moisture prone (SWAMP) zones such as engine nacelles and areas requiring overload stability, low smoke emission, and fire resistance such as aircraft cabins. Meeting the M27500 specifications, its low voltage and high temperature properties makes this wire & cable ideal for both military and commercial applications — including airframes, avionics, and ground support equipment.
M27500 specifications provide for a wide range of construction options allowing for optimal performance in virtually any environment. Any number of design components are available for users to choose from — including conductor size, number of conductors, insulation type, shield material (or no shield), circuit identification, and single or double walled jacket.
M27500-20TG4T14 Tefzel™ wire (EDMO# 20TG4T14) meets SAE AS22759/18 specifications and is a 20 gauge, shielded, 4-conductor, ETFE wire. Mil-C M27500 Spec wire & cable.
Features
- Stranded, tin-plated, copper conductor
- Extruded Ethylene tetrafluoroethylene (ETFE) insulation
- Tin-plated, copper-braided shield with 85% coverage
- Thin-walled, Extruded Ethylene tetrafluoroethylene (ETFE) Jacket
- 150°C maximum temperature
- 600 volt rating
Specifications
SAE AS22759/18 SPECIFICATIONS:
Gauge:
20 AWG
Number of Strands:
19
Strand Size:
32
Outside Diameter (Insulation):
0.049 - 0.053 in
Conductor Diameter:
0.038 in
Weight:
4.60 LB/MFT
Impedance (@ 20°C):
9.8 Ω/MFT, maximum
Number of Conductors:
4, (20TG4T14)
Mil-Spec:
M27500
NEMA Type:
WC 27500
Conductor Material:
Tin-plated copper
Insulation Material:
Extruded ethylene tetrafluoroethylene (ETFE)
Shield Material:
Tinned copper braid
Shield Coverage:
85%
Jacket Material:
Extruded ethylene tetrafluoroethylene (ETFE)
Temperature:
150°C, maximum
Voltage Rating:
600 V
SAE Specification:
SAE-AS 22759/18
M27500 SPECIFICATIONS:
Temperature Rating:
Up to 200°C (392°F) depending on the type of construction
Insulator:
(RC-06) - Polytetrafluoroethylene (PTFE)
(RC-09) – Extruded PTFE
(TE-14, TG-14) – Extruded Ethylene Tetrafluoroethylene (ETFE)
Conductor:
(RC-06, RC-09) – Stranded Silver Coated Copper
(TE-14, TG-14) – Stranded Tin Copper
Jacket:
(RC-06) – PTFE Tape
(RC-09)- Extruded FEP (RC-09)
(TE-14, TG-14) – Extruded ETFE
Other Designations:
NEMA WC 27500, SAE AS22759
Product Codes
Mfr Part No :
M27500-20TG4T14
ECCN :
EAR99
SCHEDULE B CODE :
8544.11.0050
