Absolute Pressure Sender | 5 to 50 InHg, 0.22–4.03 V, 5/8-18 Male/1/8 Female NPT

Product Description

TSO approved pressure sender units from UMA Instruments feature precise, solid state circuitry that offers excellent performance and value. They are available in gauge, differential, and absolute type sending units and compatible with avgas, jet fuel, engine oil, and many other fluids. Built-in voltage regulation allows compatibility with instruments that do not have precision output voltages. Ceramic pressure senders offer improved accuracy in a more compact, lighter weight package than standard and short body pressure senders.

This differential pressure sender unit (EDMO# 50A-B) has a pressure range of 5 to 50 InHg and a maximum pressure rating of 100 InHg.

Specifications

• Weight:
  3.0 oz
• Length:
  1.59 in
• Diameter:
  1 in
• Pressure Range:
  5 to 50 InHg
• Maximum Pressure:
  100 InHg
• Power Requirement:
  12 VDC (Regulated)
• Output:
  0.22–4.03 VDC
• Current Draw:
  20 MA
• Accuracy:
  ± 2.5%
• Sending Unit Type:
  Absolute
• Pressure Fitting:
  1/8-inch NPT
• Temperating:
  -40°C to 120°C
• Material:
  Ceramic
• Mounting Threads:
  5/8-18
• Media Compatibility:
  AVGAS, Oil, Jet Fuel, Water

Product Codes

• Mfr Part No
  T1EUMA050A-B
• SCHEDULE B CODE
  9014.20.8040
