879B Dual Display Handheld LCR Meter | 40,000 Count

879B Dual Display Handheld LCR Meter | 40,000 Count

B&K PRECISION

Call For Pricing
Available to order
EDMO # 879B
MFR Part # 879B
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The 879B 40,000-count handheld LCR meter measures inductance, capacitance, resistance, impedance, Theta, DCR, and ESR quickly and precisely. Fast auto ranging and quick measurement configuration such as measurement parameter and test frequency selection make these meters very simple to operate. The meter also includes handy functions such as data hold, Min/Max/Average recording, tolerance sorting, and relative mode. Measurement data can continuously transfer to a PC via the meter's mini USB interface, using either the provided data logging software or SCPI commands sent from a custom program.

Features

  • 40,000 counts resolution on primary and 10,000 counts resolution on secondary display
  • L, C, R, and Z (879B & 880 only) primary measurements
  • Automatic calculation of secondary parameters D, Q, Theta, ESR (Theta/ESR for 879B &880 only), and DCR (880 only)
  • Accuracy up to 0.1% and selectable test frequencies up to 100 kHz (880 only)
  • Fast auto range design for rapid, easy component measurements
  • Auto detect mode for automatic component type identification and measurement type selection (880 only)
  • Relative mode
  • Visible and audible tolerance mode
  • Backlit display (879B & 880 only)
  • Data Hold and Min/Max/Average recording
  • USB (Virtual COM) interface
  • SCPI compliant commands for remote communication
  • Software for datalogging and front panel emulation available as free download
  • Configurable power-up-states
  • All commonly requested accessories included (880 only)

Specifications

  • Weight:
    0.767 lb without battery
  • Dimensions:
    7.5 x 3.5 x 1.6 in. (190 × 90 × 41) mm
  • Measurement Parameters:
    L/C/R/Z/D/Q/θ/ESR
  • Test Frequency Setting:
    100 Hz,120 Hz, 1 kHz, 10 kHz
  • Actual Frequency (±0.02%):
    100 Hz, 120.048 Hz, 1 kHz, 10 kHz
  • Tolerance Mode:
    1%, 5%, 10%, 20%
  • Test Signal Level (Typical):
    0.6 Vrms
  • Measuring Circuit Mode:
    Series mode / Parallel mode
  • Basic Accuracy:
    0.5%
  • Ranging Mode:
    Auto
  • Measurement Rate:
    1.5 readings/sec (auto range search not included)
  • Response Time (Typical):
    680 ms
  • Auto Power-Off:
    5, 15, 30, 60 minutes, none
  • Operating Temperature:
    32° F to 104° F (0° to 40° C); 0-70% R.H.
  • Storage Temperature:
    -4° F to 122 °F (-20° to +50° C); 0-80% R.H.
  • Low Battery Indication (Typical):
    6.8 V
  • Battery Life (Typical):
    16 hours using alkaline battery (at 1 kHz with 100 Ω DUT, backlight off), 6 hours using Ni-MH (880 only)
  • Power Consumption (Typical):
    28 mA (under full power battery) for operation/ 2 µA (11 µA 880 only) after power-off.
  • Power Requirements:
    9V battery or Ext. AC adapter*: DC 12 Vmin –15 Vmax. (load 50 mA Min.)
