CC250 dual secondary 400Hz Transformer

CC250 dual secondary 400Hz Transformer

K G S ELECTRONICS

Call For Pricing
Available to order
EDMO # CC250-26
MFR Part # CC250-26
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The CC250 is a transformer designed for maximum performance while saving space and weight and dual secondary outputs. The versatile design allows for connections to be made in series or in parallel.

Features

  • Designed for maximum performance and minimum space and weight.
  • CS Series transformers for single secondary output.
  • CC Series transformers for dual secondary outputs.
  • Versatile CC series secondaries can be connected in parallel or series.
  • All primaries 115 VAC ±10%
  • Input frequency range from 380-1000 Hz.
  • Transformer regulation is 6% no load to full load.
  • Operating temperature +71°c to -55°c.
  • Designed to meet RTCA DO-160C environmental conditions.
  • Secondary voltages between the standard units available.

Specifications

  • Weight:
    2.5 lb
  • Dimensions:
    3 3/8 x 3 3/8 x 3 1/4 in
  • Mounting Dimensions:
    2 1/2 x 1 7/16 in
  • Eo(RMS):
    26 parallel, 52 secondary
  • Amps (RMS):
    10 parallel, 5 secondary

Related Products

Product Codes

  • Mfr Part No
    CC250-26
  • SCHEDULE B CODE
    9014.20.6000
