H-C High Temperature Solder Sleeve | 0.030 – 0.125 O.D., 150°C


SUMITOMO

EDMO#: H-C-2

MFR#: STS H-C-2

Description

H-C-series high temperature solder termination sleeves (STS) provide a reliable method of terminating a wide variety of coaxial cables and screens. They can be used for wire-to-wire, wire-to-pin connections, and triaxial cable assemblies. STS are designed to solder, seal terminations, provide strain relief and are installed by the application of heat.


This H-C solder sleeve terminal (EDMO# H-C-2) fits wire diameters of 0.030 (øD4) and 0.125 (øD2). *see Datasheet

Features

  • NAS 1745 & NAS1744 Qualified
  • Immersion Resistant
  • 150°C Operating Temperature
  • 183°C Solder Melt Temperature
  • Convection heated installation

Specifications

Operating Temperature:
-55°C to 150°C

Solder Melt Temperature:
183°C

Solder Type:
Sn63 (63% tin, 37% lead)

Temperature Indicating Paint (TI):
Yes

Jacket Type:
Radiation Cross-Linked Modified Polyolefin

Includes Lead Wire:
No

Includes Braid:
No

Environmental seals:
Yes

RoHS Compliant:
No

Flux:
RMA

Product Codes

Mfr Part No :

STS H-C-2

ECCN :

EAR99

NAS :

1745-2

SCHEDULE B CODE :

8536.69.4050

Documentation

Notice: EDMO Distributors, Inc. has made every effort to verify the accuracy of the codes, classifications, and part approvals listed in accordance with the Department of Commerce, U.S. Census Bureau, Bureau of Industry and Security, U.S. Department of Defense and Federal Aviation Administration. EDMO Distributors, Inc. does not assume responsibility for errors or omissions. This listing is subject to change without notice.

Warning to Exporters: EDMO Distributors, Inc. does not assume responsibility for errors with any of the Schedule B Commodity Codes or Export Control Classification Numbers in this listing. It is the Exporter's responsibility to research and supply the correct codes and classifications for the product to be exported. Some products may require an Export License in order to be exported.
