ProFIT® HIX Heat Shrink Tubing | White, 1 1/2 in, 4 ft

ProFIT® HIX Heat Shrink Tubing | White, 1 1/2 in, 4 ft

ICO RALLY

Call For Pricing
Available to order
EDMO # HIX-1 1/2W
MFR Part # HIX-1-1/2 WHITE
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

ProFIT® HIX general purpose polyolefin heat-shrinkable tubing is used for insulating, jacketing, bundling, and identifying wire and cables. HIX tubing is mechanically tough and resistant to abrasion and solvents while providing a longitudinal shrinkage less than 6%.

This HIX heat shrink tubing (EDMO# HIX-1 1/2W) has a 1-1/2 inch diameter, colored white, and comes as a 4 foot stick.

Features

  • Application specifications: SAE-AMS-DTL-23053/5, Class 1 and 2
  • UL File Number: E52612 (VW-1 except Clear)
  • Operating Temperature: -67°F to 275°F (-55°C to 135°C)
  • Shrink Ratio: 2 to 1
  • Shrink Temperature: 250°F (121°C)
  • Color: white (other colors available)

Also Purchased

Specifications

  • Diameter:
    1-1/2 in
  • Length:
    4 ft per stick
  • Minimum Expanded I.D.:
    1.500 in (38.10 mm)
  • Maximum Recovered I.D.:
    0.750 in (19.05 mm)
  • Recovered Wall Thickness:
    0.040 in (1.01 mm)

Related Products

Product Codes

  • Mfr Part No
    HIX-1-1/2 WHITE
  • MIL SPEC
    M23053/5-111-9
  • MIL SPEC
    M23053/5-111-9
