ProFIT® HIX Heat Shrink Tubing | Yellow, 3/4 in, 4 ft

ProFIT® HIX Heat Shrink Tubing | Yellow, 3/4 in, 4 ft
ProFIT® HIX Heat Shrink Tubing | Yellow, 3/4 in, 4 ft
ProFIT® HIX Heat Shrink Tubing | Yellow, 3/4 in, 4 ft

ICO RALLY

EDMO#: HIX-3/4YE

MFR#: HIX-3/4YE

Description

ProFIT® HIX general purpose polyolefin heat-shrinkable tubing is used for insulating, jacketing, bundling, and identifying wire and cables. HIX tubing is mechanically tough and resistant to abrasion and solvents while providing a longitudinal shrinkage less than 6%.

This HIX heat shrink tubing (EDMO# HIX-3/4YE) has a 3/4 inch diameter, a 2:1 shrink ratio, colored yellow, and  comes as a 4 foot stick.

Features

  • Application specifications: SAE-AMS-DTL-23053/5, Class 1 and 2
  • UL File Number: E52612 (VW-1 except Clear)
  • Operating Temperature: -67°F to 275°F (-55°C to 135°C)
  • Shrink Ratio: 2 to 1
  • Shrink Temperature: 250°F (121°C)
  • Color: yellow (other colors available)

Specifications

Diameter:
3/4 in

Length:
4 ft per stick

Minimum Expanded I.D.:
0.750 in (19.05 mm)

Maximum Recovered I.D.:
0.375 in (9.53 mm)

Recovered Wall Thickness:
0.030 in (0.79)

Product Codes

Mfr Part No :

HIX-3/4YE

MIL SPEC :

M23053/5

ECCN :

1C008

MIL SPEC :

M23053/5

SCHEDULE B CODE :

3902.30.0000

Notice: EDMO Distributors, Inc. has made every effort to verify the accuracy of the codes, classifications, and part approvals listed in accordance with the Department of Commerce, U.S. Census Bureau, Bureau of Industry and Security, U.S. Department of Defense and Federal Aviation Administration. EDMO Distributors, Inc. does not assume responsibility for errors or omissions. This listing is subject to change without notice.

Warning to Exporters: EDMO Distributors, Inc. does not assume responsibility for errors with any of the Schedule B Commodity Codes or Export Control Classification Numbers in this listing. It is the Exporter's responsibility to research and supply the correct codes and classifications for the product to be exported. Some products may require an Export License in order to be exported.
