Re-Radiating L1 GPS Passive Antenna | BNC Connector

Product Description

The L1RRKPA-B GPS repeater antenna is a passive antenna designed specifically for the GPS L1 carrier frequency. This antenna provides a signal indoors to test GPS equipment.

This L1-band gps re-radiating antenna (EDMO# L1RRKPA-B) features a BNC type connector.

Specifications

• Weight:
  48 g, max.
• Dimensions:
  66 x 66 x 18 mm
• Temperature:
  -40°C to 85°C, operating -50°C to 95°C, storage
• Vibration:
  Sine sweep, 1 G(0-P), 10-150-10Hz each axis
• Humidity:
  95% to 100% RH
• Center Frequency:
  1,575.43 ±3 MHz
• Impedance:
  50Ω
• Polarization:
  Right-hand circular polarized
• Axial Ration:
  3 dB
• VSWR:
  1.5:1
• Power Handling:
  4 dBic
• Gain Coverage:
  ≥ ‐4 dBic @ ‐90° ≤ θ ≤ 90° (over 75% volume)
• Connector Option:
  BNC-type

Product Codes

• Mfr Part No
  L1RRKPA-B
