Re-Radiating L1 GPS Passive Antenna | SMA Connector

Re-Radiating Antenna / SMA connector

GPS NETWORKING

Call For Pricing
Available to order
EDMO # L1RRKPA-S
MFR Part # L1RRKPA-S
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The L1RRKPA-SGPS repeater antenna is a passive antenna designed specifically for the GPS L1 carrier frequency. This antenna provides a signal indoors to test GPS equipment.


This L1-band gps re-radiating antenna (EDMO# L1RRKPA-S) features a SMA type connector.

Features

  • Specifically designed for the GPS L1 carrier frequency
  • Re-radiants gps frequencies indoors

Specifications

  • Weight:
    48 g, max.
  • Dimensions:
    66 x 66 x 18 mm
  • Temperature:
    -40°C to 85°C, operating -50°C to 95°C, storage
  • Vibration:
    Sine sweep, 1 G(0-P), 10-150-10Hz each axis
  • Humidity:
    95% to 100% RH
  • Center Frequency:
    1,575.43 ±3 MHz
  • Impedance:
    50Ω
  • Polarization:
    right-hand circular polarized
  • Axial Ration:
    3 dB
  • VSWR:
    1.5:1
  • Power Handling:
    4 dBic
  • Gain Coverage:
    ≥ ‐4 dBic @ ‐90° ≤ θ ≤ 90° (over 75% volume)
  • Connector Option:
    SMA-type

Related Products

Product Codes

  • Mfr Part No
    L1RRKPA-S
  • ECCN
    7B994
  • SCHEDULE B CODE
    8526.91.0070
