PE9562 TNC Male to C Female Adapter | 50Ω, MIL-STD-348

Product Description

RF adapters are often used to enable connections between two connector types that would otherwise not mate. Certain adapter configurations can also be used to protect connectors on expensive equipment where the number of connect/disconnect cycles is high. An RF, microwave or millimeter wave adapter is connected to the equipment, and the commonly changed connection is made with the adapter which can be easily replaced when it wears out after high usage.

This TNC male to C female adapter (EDMO# PE9562) features a straight body geometry and a silver-plated contact. This connector also has a 50Ω impedance and is MIL-STC-348 compliant.

Specifications

• Weight:
  0.06 lb (27.22 g)
• Dimensions:
  1.325 x 0.63 in (33.66 x 16 mm)
• Connector Type:
  TNC male (connector 1) C female (connector 2)
• Polarity:
  standard
• Interface Specifications:
  MIL-STD-348
• Contact Material:
  Silver (QQ-S-365)
• Insulation Material:
  PTFE
• Outer Conductor:
  nickel-plated brass (QQ-N-290)
• Body Material:
  nickel-plated brass (QQ-N-290)
• Coupling Nut Material:
  nickel-plated brass (QQ-N-290)
• Operating Temperature:
  -65°C to 165°C

Product Codes

• Mfr Part No
  PE9562
• SCHEDULE B CODE
  8536.69.4010
