pingStation 3 Networkable Weatherproof 978/1090 ADS-B Receiver

UAVIONIX

Call For Pricing

In stock

EDMO # PNGSTN3

MFR Part # UAX-90083-01

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The pingStation 3 receives both ADS-B frequencies on 978 MHz UAT and 1090 MHz simultaneously with a single installation and allows local airports to track ADS-B equipped aircraft up to 200+ miles away. It supports ASTERIX CAT 021 message formats for global compatibility with air traffic management standards, as well as addition formats for supporting integration with any display system or data logger.

Features

Networkable, weatherproof 978 & 1090 ADS-B receiver
Dual band ADS-B reception
Supports enterprise data formats such as ASTERIX CAT 021 message formats
Provides data in several formats for easy integration into any display or analytical application
Weather resistant and easy to deploy

Specifications

Dimensions:

673.70 x 178.45 x 36 mm
Input Voltage / Power:

44-57V / 350mA Power over Ethernet
Weight:

545 grams
Receive
Specification

MTL 1090MHz Dynamic Range: -88dBm -79 to 0dBm
MTL 978MHz Dynamic Range:

-93dBm -90 to -3dBm Interface: Asterix CAT021 Ethernet (JSON UDP) Compressed VRS (Virtual Radar Server)
