Variable Linear Power Supplies | 10—37A continuous

Variable Linear Power Supplies | 10—37A continuous

ASTRON

Call For Pricing
Available to order
EDMO # VS-50M
MFR Part # VS-50M
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The VLS-50M is a solid state electronically regulated power supply with fold-back current limiting to protect the power supply from excessive current or shorted output. Chassis mounted fuse and less than 5mV ripple peak to peak (full load and low line).

This VLS-50M power supply (EDMO# VS-50M) has a variable 10A — 37A continuous power.



Features

  • Solid state electronically regulated
  • Fold back current limiting protects power supply from excessive current and continuous shorted output
  • Crowbar over voltage protection on all models
  • Maintain regulation and low ripple at low line input voltage
  • Three-conductor power cord
  • Heavy duty heat sink
  • 22 VDC — 32 VDC Externally Adjustable Voltage
  • RIPPLE: LESS THAN 5MV PEAK TO PEAK (full load and low line)
  • LOAD REGULATION: 0.08% from 0 to Full Continuous Load​​
  • 77% efficiency rating

Specifications

  • Dimensions:
    6 x 13-3/4 x 11 in
  • Weight
    : 46 lb
  • Continuous Duty:
    @13.8 VDC: 37 amps @10.0 VDC: 22 amps @05.0 VDC: 10 amps
  • ICS*:
    @13.8 VDC: 50 amps @10.0 VDC: 24 amps @05.0 VDC: 11 amps
  • Fuse:
    GMC 10A
  • Power Terminals:
    1/4"-20 Screw Type
  • AC Current Draw:
    Idle: 324 mA Full Load: 8.17A
  • Fan Cooled:
    No

Related Products

Product Codes

  • Mfr Part No
    VS-50M
  • SCHEDULE B CODE
    8504.40.9580
