TY92 VHF Transceiver | Remote Unit with Mounting Tray

TRIG AVIONICS

Call For Pricing

Available to order

EDMO # 00881-00

MFR Part # 00881-00-01

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

Designed for GA and light sport aircraft, the TY91 and TY92 are certified 25 kHz/8.33 kHz VHF radios that are compact and lightweight — making them ideal for panels with limited space. Users can choose from one of two power output options. The TY91 has a power output of 6 watts and the TY92 has a power output of 16 watts to accommodate longer-range transmissions. The TY92 has a higher power output of 16 watts which is suitable for longer range transmission and requires a 28V power supply.

This TY92 transceiver (EDMO# 00881-00) includes the remote unit and mounting tray without the control unit.

Features

Compact and lightweight offers flexible installation options
8.33 and 25 kHz channel spacing
Push Step feature provides fast frequency selection
Monitor two frequencies at the same time with the dual watch function
Manual dimming feature
Dual controller option allows for two controllers to used in aircrafts with tandom conpits
Low power consumption
6 watts nominal output
Simple installation
EASA ETSO and FAA TSO certification

Specifications

Weight:

460 grams
Dimensions:

44 x 63 x 35 mm (controller) 48 x 66 x 160 mm (radio unit)
Cooling Requirement:

No fan required
Operating Temperature:

-20°C to 70°C (controller) -40°C to 70°C (radio unit)
Channel Spacing:

8.33 kHz / 25 kHz transceiver
Receiver:

Class C, Class E (TY91) Class C, Class E (TY92)
Transmitter:

Class 4, Class 6 / 6 watt (TY91) Class 3, Class 5 / 16 watt (TY92)
Supply Voltage:

11-33 VDC (TY91) 22-33 VDC (TY92)
Typical Current:

200 mA receive (TY91) 130 mA receive (TY92)
Consumption:

2A transmit @ 14V (TY91) 2.5A transmit @ 28V (TY92)
Nominal Transmitter Power:

6W (TY91) 16W (TY92)
Certification:

ETSO-2C169a, ETSO-2C128, TSO-C169a, TSO-C128a
Compliance:

ED-23C, ED-67, DO-186B, DO-178B Level B, DO-160F, DO-254 Level C
