110-320 Tri-Band ELT Rod Antenna | Dual Input, 121.5/243/406MHz, White

ACR ELECTRONICS / ARTEX

Call For Pricing

Available to order

EDMO # 110-320

MFR Part # 110-320

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The Artex 110-320 antenna is designed with a glass-reinforced, polyester housing and uses proprietary Tri-Band technology to provide signal transmission on 121.5, 243, and 406 MHz with 10 dB of isolation between ports. Use #280-0320, optional gasket for 110-320 for installation.

Features

White
Tri-Band technology
Dual input BNC, TNC
121.5, 243, and 406 MHz frequencies
Vertical polarization
Omni-directional radiation pattern
Tough glass reinforced polyester housing
Designed to meet the Eurocae ED 62 flame test

Also Purchased

Specifications

Specification

Weight: 0.45 lb
Specification

Height: 15.50 in.
Specification

Frequency: 121.5, 243 & 406 MHz
Specification

VSWR: 2.0:1 - 121.5/243 MHz, 1.5:1 - 406 MHz
Specification

Polarization: Vertical
Specification

Radiation Pattern: Omni-directional
Specification

Impedance: RF 50 OHMS (nominal)
Power:

25 watts
Specification

Material: Molded radome/fiberglass whip
Specification

Finish: Polyurethane enamel
Specification

Connector: BNC (female) for 121.5/243 MHz, TNC (female) for 406 MHz
Specification

Temperature: -55˚ C to + 85˚ C
Specification

Altitude: 50,000 ft
Specification

Color: White
Gasket:

B31725(optional to order separately)
