MS27039-1-06 Pan Head Machine Screw | 10-32 Thread, 13/32-inch Thread Length, 7/16-inch Fastener Length, 0.373-inch Phillips Head

Product Description

This MS27039 series pan head machine screw (EDMO# 27039-1-06) has 10-32 threads, a 0.373-inch Phillips head, 13/32-inch thread length, and 7/16-inch fastener length. It is also made of cadmium plated steel.

Specifications

• Thread Class:
  3a
• Thread Direction:
  Right-hand
• Thread Length:
  0.40625 in
• Fastener Length:
  0.4375 in
• Head Style:
  Pan Head
• Head Diameter:
  0.357 – 0.373 in
• Internal Drive Style:
  Cross recess type 1
• Nominal Thread Diameter:
  0.190 in
• Thread Quantity Per Inch:
  32
• Minimum Tensile Strength:
  125000 lb/sq. in
• Screw Material:
  Steel, Cadmium Plated
• Thread Series Designator:
  UNF

Product Codes

• Mfr Part No
  MS27039-1-06
• MIL SPEC
  MS27039-1-06
• ECCN
  EAR99
• MIL SPEC
  MS27039-1-06
• SCHEDULE B CODE
  7408.29.0000
