ARINC 429 Databus Analyzer

ATG

Call For Pricing

Available to order

EDMO # 429EX

MFR Part # 01-1001-05

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The 429EX ARINC 429 Databus Analyzer provides avionics technicians and line maintenance personnel with an easy method for troubleshooting ARINC 429 labels. It has the capability to selectively trap labels three different ways. The 429EX has a non-volatile memory and features user-selectable ARINC Air Transport Equipment Identifier Codes. Transmitted and received data can be viewed in either hexadecimal or easy-to-understand engineering format.

The 429EX is housed in a rugged, compact case with internal, rechargeable NiCad batteries. The unit comes with either a 110V or 230V plug-in battery charger. An optional carrying case is available (sold separately) for convenience and protection of the unit.

Features

Transmitter Operation:
Data entry in Hexadecimal or Engineering Units
Can transmit up to 10 labels simultaneously
Selectable (Lo or Hi speed) bit rate
Selectable (Odd or Even) word parity
Selectable (4 to 59995 ms) word rate
Selectable Hex I.D. for display of data per ARINC 429-11
Non-volatile memory storage
Data slewing of non-RF labels
On/Off toggling of individual data bits 11 through 29
LED display of transmitted word parity
Receiver Operation:
Data display in Hexadecimal or Engineering Units
Trapping and storing of up to 255 words (511 in Data Only mode)
Allows trapping of block data protocols or alphanumeric data strings
Non-volatile memory of trapped data
Automatic scrolling of trapped data
Individual display of bits 11 through 29
Selectable Hex I.D. for display of data per ARINC 429-11
Selectable (Lo or Hi speed) bit rate
LED display of received word parity

Also Purchased

Specifications

Weight:

3 lb
Dimensions:

7.25 x 4.5 x 2.5 in
Input Power Requirements:

110 VAC, 60 Hz @ 500 mA 230 VAC, 50 Hz @ 300 mA Six (6) internally mounted AA size rechargeable NiCad batteries
TRANSMITTER OPERATION

Pulse Rise/Fall Time: Lo speed: 10.0 ±5.0 µs Hi speed: 1.5 ±0.5 µs
Voltage Levels:

HI: 10.0 ±1.0 VDC NULL: 0.0 ±0.5 VDV LO: -10.0 ±1.0 VDC
Output Impedance:

75 ±5 Ω (Line A to B)
Bit Rate:

Low speed: 12.5 kbps ±0.5% Hi speed: 100.0 kbps ±0.5%
Word Rate:

4 to 59998 ms (selectable)
Parity:

ODD or EVEN (selectable)
RECEIVER OPERATION

Bit Rate: Low speed: 8 to 20 kbps Hi speed: 80 to 125 kbps
Voltage Levels:

HI: 6.5 to 13.0 VDC NULL: 2.5 to -2.5 VDC LO: -6.5 to -13.0 VDC
Word Rate:

±2 ms, average
Input Impedance:

12 kΩ, minimum (balanced)
