Underwater Locator Beacon
DUKANE
EDMO#: DK290
MFR#: DK290-11
Hazmat charges may apply
Description
The DK290 ULD is Dukane Seacom's advanced ULD that leverages the design-features of the existing DK120/90 with improved battery safety features including a new non-restricted Class-9 lithium battery and containment of thermal runaway. It is designed to aid in the retrieval of the Cockpit Voice and Flight Data Recorders (CVFDR).
With the hazards of lithium batteries emerging in the aviation industry, the DK290 was developed with battery safety at the forefront of all design considerations resulting in a ULD with reduced lithium content and capable of safely containing a thermal runaway event.
The DK290 was designed with the uncompromising goal of improving battery safety onboard the aircraft and during the shipment while ensuring the functionality required by TSO-C121b and TSO-C142b. The Dukane Seacom DK290 and its batteries have been tested and certified to applicable requirements specified in SAE AS8045A, RTCA/DO-160G, and RTCA/DO-227A standards. The ULD meets or exceed the minimum performance standards required for TSO-C121b approval.
The DK290 utilizes the field-proven Lithium Manganese Dioxide battery chemistry avoiding the use of other contentious chemistries such as Lithium Thionyl Chloride and Lithium Sulfuryl Chloride, which have been deemed unfit for use by many in the aviation industry. In addition, our Lithium Manganese Dioxide battery chemistry is far superior to unproven Alkaline technology for this application in terms of performance in harsh environments and temperature extremes over a six-year battery life.
Features
- Non-restricted Class-9 lithium battery
- TSO-C121b, TSO-C142b, and DO-227A compliant
- Full containment of battery thermal runaway
- Improved performance and safety
- Enhanced omnidirectional acoustic output
- Proven battery technology for airborne applications
- New dual water switch and hard anodized housing
- 90-days operation
- 6-year customer-replaceable battery
- RoHS & REACH compliant
- Same form factor as current DK100/DK120/DK100-90/DK120-90
Specifications
Weight:
<6.7 oz
Dimensions:
1.30 x 3.93 in
Operating Frequency:
37.5 kHz ± 1 kHz
Operating Depth:
Surface to 20,000 feet (6,096 meters)
Pulse Length:
9.0 ms (min)
Pulse Repetition Rate:
0.9 PPS (min)
Useful Life:
6 years
Operating Life:
90 days (min)
Acoustic Output, Initial:
1060 dynes/cm2rms pressure at 1 meter (160.5dB)
Acoustic Output, After 30 days:
700 dynes/cm2rms pressure at 1 meter (157.0dB)
Operating Temperature:
28°F to 100°F (-2.2°C to 37.8°C)
Actuation:
Fresh or salt water
Radiation Pattern:
Rated output over 80% of sphere
Material:
7075-T6 Aluminum, anodized finish
Power Source:
Two ULD batteries, multi-cell (<2g Lithium)
Storage Temperature:
-67°F to 185°F (-55°C to 85°C)
FAA Authorized:
TSO-C121b (ULD)
TSO-C142b (ULD Battery)
Performance:
SAE AS8045A (ULD)
RTCA DO-227A (ULD Battery)
Product Codes
Mfr Part No :
DK290-11
END USE :
SEALDYNAMICS
SCHEDULE B CODE :
9014.80.6000
