Fluke 114 Electrical Multimeter

ELECTRICIANS DIGITAL MULTIMETER/CAT III 600 V safety rating, VoltAlert technology, AutoVolt automatic AC/DC voltage selection, low input impedance, LED backlight.

FLUKE

Call For Pricing
Available to order
EDMO # FLUKE 114
MFR Part # FLUKE-114
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

Designed for easy one-handed operation, the compact Fluke 114 Electrical Multimeter is the perfect troubleshooting tool for go/no go testing. Its AutoVolt capability automatically switches to measure AC or DC voltage, whichever is present. The LoZ function is used to identify so-called ghost voltage and prevent false readings.

The Fluke 114 displays True-RMS voltage and current readings with 6000 count resolution, and tests frequency, continuity and resistance. A large white LED backlight aids work in poorly lit areas. And its easy-open battery access door makes battery changes easy.

The Fluke 114 Electrical Multimeter is CAT III 600 V safety rated.

Features

  • Includes:
  • Holster, installed 9 V battery, test leads, user manual
  • Features:
  • Comes with an holster with probe holders for easy storage
  • Compact ergonomic design for one-handed operation
  • Features manual and automatic ranging
  • Safety rates CAT III 600 V
  • Fits into optional ToolPak™ magnetic hanger for hands-free operation

Specifications

  • Weight:
    550 g
  • Dimensions:
    167 x 84 x 46 mm (6.57 x 3.31 x 1.82 in)
  • Maximum voltage:
    600 V (between any terminal and earth ground)
  • Safety:
    IEC 61010-1: Pollution Degree 2 IEC 61010-2-033: CAT III 600V
  • Display:
    Digital: 6,000 counts, updates 4 per second
  • Bar graph:
    33 segments, updates 32 per second
  • Operating temperature:
    -10°C to + 50°C
  • Storage temperature:
    -40°C to + 60°C
  • Battery type:
    9 volt Alkaline, IEC 6LR61
  • Battery life:
    400 hours typical, without backlight
  • Warranty:
    3 years

Related Products

Product Codes

  • Mfr Part No
    FLUKE-114
  • ANSI
    ANSI/ISA 82.02.01 (61010-1) 2004
  • CSA
    CAN/CSA C22.2 No 61010-1-04,
  • ECCN
    EAR99
  • SCHEDULE B CODE
    9025.19.8080
  • UL
    UL 6101B (2003)
