Panel Pro | Model 6126, Milwaukee Router

BULLER ENTERPRISES

Call For Pricing

Available to order

EDMO # 1-0300-00D

MFR Part # 1-0300-00D

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The Panel Pro™ model 6126 is a computer controlled router optimized for aluminum sheet metal 1/8″ thick and designed to create custom aircraft instrument panels. It has an x axis (width) travel of 59 inches, y axis (height) travel of 25 inches, and a z axis (up and down) travel of 3.125 inches. With multiple passes, aluminum as thick as 1/2″ can be cut. All 3 axis are computer driven with heavy duty NEMA size 23 stepper motors.

Version (EDMO#1-0300-00D) includes Panel Pro 6126, Milwaukee router, SC3 Controller, SC3 Software, AvCam (Panel Pro Operating System), QCAD and Drawing Library, Coolant pump and 5 Gallon Tank Assembly.

Features

Includes:
The Panel Pro™ 6126 machine tool
SC3 controller with software
Interconnect cables
Milwaukee variable / regulated speed router with a collet adapter to use industry standard ER11 collets. 1/8, 3/16, and 1/4″ collets are provided
AvCAM version 19 machine operation software
QCAD 2D computer aided drafting software
Extensive aircraft instrument panel and instrument drawing library
Coolant system with 1 gallon coolant
Starter supply of high strength carbide end mills
Hand tools needed for operation
Pen plotter adapter to draw out panels or parts in full size
Features:
Milwaukee router
3 axis operations
Can edge chamfer and inset
Compatible materials: Aluminum sheet, plastic, honeycomb, carbon fiber, 4130 steel
Small footprint, 4 ft by 6 ft
Mechanical splash guard
Emergency shut off
