602T DYNAMIC AVIATION MICROPHONE - Blade hanger mount, XLR-4-12C

Product Description

The 602T is a handheld dynamic microphone designed for highly articulate speech transmission under high ambient noise. The 602T uniquely meets the specialized requirements of airline, two-way radio and industrial applications. Transistorized with a pressure-gradient microphone utilizing three sound entrances for reduction of inter-facing ambient noise. This mic is unexcelled at discriminating between near and distant sounds for maximum ambient noise rejection. The compact single stage transistor amplifier is specially stabilized and will operate uniformly from +550 C down -200 C.

Specifications

• Type:
• Frequency Response:
  300 - 5,000 Hz
• Impedance:
  Matches standard aircraft carbon circuitry Sensitivity: 400 mV ±3 dB for 114 dB re 20u pascals Current Drain: 12.3 mA at 8 Vdc (12-volt system) 25.0 mA at 16 Vdc (24-volt system) Case Material: Black ABS Dimensions: 101.6 mm (4.0 in) length, less hanger, 72.1 mm (2.84 in) width 59.4 mm (2.34 in) depth Weight: 325 g (11.4 oz) Certification: FAA TSO C58a, Category B

Product Codes

• Mfr Part No
  602-3373
• ECCN
  7A994
• SCHEDULE B CODE
  8518.10.0000
• TSO
  C58a
