MIT320 Insulation and Continuity Tester

INSULATION & CONTINUITY TESTER

MEGGER

EDMO#: MIT320EN

MFR#: MIT320-EN

Description

The Megger MIT320 insulation and continuity tester features a digital and analog display with large 20mm high characters for providing a clear reading of test results. The analog arc display provides users with a true analog response. The combination of insulation and continuity testing allows this instrument to be used in all aspects of electrical wiring. The MIT300 series electrical testers are ideal for both commercial and industrial applications including electrical contracting, building maintenance, testing, inspecting and servicing.

Features

  • Easy to operate
  • Constructed using tough, rubberized case
  • Self-contained protective cover
  • Live circuit warning
  • Weatherproof IP54 rating
  • Protected with an intelligent safety system for protection
  • Store and download test results
  • Download software included
  • USB interface

Specifications

Weight:
980 g

Dimensions:
8 x 5.7 x 3.2 in (203 x 148 x 78 mm)

Insulation Test Range (DC):
1,000V, 500V, 250V

Continuity Measurement Range:
0.01Ω – 99.9Ω on analog scale

Resistance Measurement Range:
10Ω – 1MΩ

Voltage Measurement Range:
0 - 600VAC, (50/60Hz)

Interface:
USB

Temperature Range:
-10°C to 60°C, operating
-25°C to 70°C, storage

Operating Humidity:
93% R.H. @ 40°C, max.

Battery:
8 x 1.5V (AA alkaline cells)

Fuses:
Terminals 500 mA (F) 600V, 32x6 mm Ceramic HBC 10kA

Environmental Protections:
IP54

Safety:
Meets IEC61010-1 Cat III 600V phase to earth

Product Codes

Mfr Part No :

MIT320-EN

ECCN :

7B994

SCHEDULE B CODE :

9031.80.8080
