Biaxial Shielded Telephone Jack Connector | 8-Connector, 2-Switch

Product Description

This TJSS biaxial shielded telephone jack  connector features an eight-connector, two-switch design for military and commercial purposes.

This jack connector (EDMO# TJSS-108) features a two-switch design and eight-conductors.

Specifications

• Dimension:
  1.047 x 1.969 x 2.609 in
• Application:
  Military / Ruggedized Commercial
• Number of Conductors:
  8
• Contact Diameter:
  0.285 in
• Shell Material:
  plastic
• Contact Material:
  Nickel-plated, beryllium copper
• Solder Contact Terminals:
  Pre-tinned over nickel plating
• Contact Resistance:
  ≤ 0.02 mΩ
• ≥ 1,000 mΩ
• Dielectric Withstanding Voltage:
  ≥ 500 mΩ RMS
• Insertion Force:
  13 lb
• Withdrawal Force:
  6 to 10 lb

Product Codes

• Mfr Part No
  TJSS-108

Documentation

• TJSS-108 Drawing
